Wolf Tandem Independent Suspension Electric Off Road 4000kg KYB Shocks

The Australian Made Wolf Independent Suspension a heavy-duty solution meticulously designed by our engineers for the toughest conditions, from the rugged paths of Palmer River to the expanses of Simpson Dessert. The Wolf Independent Suspension stand out not only for its durability but also as a testament to Australian craftsmanship. Prioritizing durability and dependability, this system reduces unsprung weight by minimizing component mass unsupported by suspension. Installed with long lasting quality KYB shock absorbers, you won’t have to worry about overheating or a stiff ride. The Wolf Independent Suspension is locally made in Australia and boasts a massive 5 year warranty. Advantages

• Australian made, with 5 years warranty*
• Smoother rides on demanding terrains
• Adjustable camber & toe
• Self lubricating Delrin bushes
• Optimized performance with KYB shock absorbers
• Pick your Desired Colour

What’s Included

• 4 x Independent Trailing Arms
• 4 x Pivot bar with Adjustable Toe & Camber
• 8 x Bumper Stops
• 4 x Chrome Silicon Coils with Mounting Brackets, High Tensile Bolts and All Hardware
• 8 x KYB Tena Force Heavy Duty Shocks
• 4 x 12″ Off Road Electric Backing Plates
• 4 x 12″ Electric Drums Complete with Japanese Koyo Bearings, Seals, Duct Caps and Nuts
• All High Tensile Nuts and Bolts Included

• Fitted with KYB shocks designed for the toughest Australian terrain
• An Australian made product that is backed by a comprehensive 5 year warranty
• A low maintenance reliable ride built on robust engineering and design.
• We can collaborate directly with you or your trailer manufacturer or suggest and deliver direct to one of our partner trailer manufacturers.

Specification	Value
Load Rating	4000kg
Made In	Australia
Brake Type	Electric
Brake Size	12″
Shock Absorber	KYB
Shock Absorber Fluid	All Weather Fluids
Trailing Arm Material	BlueScope Steel
Trailing Arm Coating	E-Coated &/or Powder Coated (Depending on colour)
Coil Spring Material	Chrome Silicon
Bearings Type	Koyo Japanese
Warranty	5 Years
Tandem Axle Centres (Wheelbase)	830mm
Cross Member distance	780mm
Recommended Chassis to Wheel Clearance	50mm
Installation Guide	Refer to Resources & Downloads
